ZXHN F670L Dual Band GPON ONU
ZTE f670l is a dual band Gigabit Premium triple-play GPON gateway. It comes with 1GE&3FE LAN ports, one phone port and next generation multi-stream Wi-Fi, operating simultaneously in 2.4GHz 2×2 over 802.11n and 5GHz 2×2 over 802.11ac. Based on customer requirements, the maximum 5dBi gain antennas can enhance the Wi-Fi coverage area and improve the performance.
- Dual-band GPON gateway features 5dBi high-gain antennas for extended Wi-Fi coverage.
Its 2×2 MIMO technology eliminates dead zones, ensuring stable connectivity across multi-room homes and small offices.
Ideal for seamless streaming, gaming, and smart home device connections. - Engineered for carrier-grade triple-play services, the ZXHN F670L supports high-speed internet, IPTV, and VoIP.It packs 1GE+3FE LAN ports and 1 POTS port, meeting all wired and voice connectivity needs.A reliable choice for ISPs deploying comprehensive broadband solutions.
- Powered by simultaneous 2.4GHz 802.11n and 5GHz 802.11ac Wi-Fi, the F670L delivers multi-stream performance.It balances speed for bandwidth-heavy tasks and compatibility for legacy wireless devices.Perfect for users requiring both fast speeds and broad device support.
- The gpon ont zxhn f670l integrates seamlessly with existing GPON OLT infrastructure.Its plug-and-play design simplifies installation for both new deployments and network upgrades.A cost-effective, future-proof ONU for FTTH and FTTB broadband access projects.
| Model | F670L |
| GPON Port | 1x, SC/APC, 2,448 Gbit/s downstream 1,244 Gbit/s upstream |
| Subscriber interface | 4GE+1pots+1USB+WIFI 2.4G &5G |
| Modes | Bridge, Router, AP |
| Wavelength downstream | 1490nm |
| Upstream Wavelength | 1310nm |
| Sensitivity | -28 dBm |
| Consumption | 9 W |
| Dimensions | 205 x 120 x 28 mm |
| Working temperature and humidity | 0°C – 40°C, 5% – 95% |
| Power | 12 IN DC |
| GPON properties | 8x T-CONT, 32 GEM ports |
| Support | VLAN (802.1Q, 802.1P, 802.1ad), Multicast, QoS, DHCP Server/Client, NAT, IPv6 Dual Stack |
| Management | Local (WEB), OMCI, TR069 |
